President ACMD901 Cooling Fan Kit for the President Washington
President ACMD901 Cooling Fan Kit for the President Washington
The President ACMD901 is the factory-designed cooling fan kit for the President Washington 10 meter radio. The Washington ships without a fan from the factory, and President Electronics recommends adding one — or a pair — for long transmissions, heavy repeater duty, and high-duty-cycle operation on 10 and 12 meters.
This kit adds a genuine President-branded 40 mm fan directly to the Washington's rear heatsink. Once installed, the radio's built-in APM (Automatic Power Management) system controls the fan automatically based on internal temperature — no external switching, no wiring hacks, no manual on/off. The Washington was purpose-built to accept up to two of these fans, so you can start with one and add a second later.
Who this fan kit is for
- Washington owners running long SSB or repeater sessions. Extended transmit duty at 90W+ generates real heat inside the chassis. The ACMD901 keeps the finals in their happy zone.
- Base station operators. A base install with a 13.8V power supply and long ragchews benefits significantly from active cooling.
- Truckers on high-duty-cycle nets or open channels. If you spend hours on the mic in a hot cab, this is a no-brainer add-on.
- Owners who want to preserve their warranty and heat headroom. This is the OEM-approved cooling accessory — using it doesn't void anything, and the kit even includes replacement warranty stickers to restore the case after installation.
What's in the box
- 1 × President ACMD901 40 mm cooling fan
- 1 × metal protective grille
- 4 × mounting screws
- 2 × replacement warranty stickers
- 1 × installation instruction sheet
Specifications
| Manufacturer part number | ACMD901 |
| Compatible with | President Washington (all versions, including the current 100W model) |
| Fan size | 40 × 40 × 20 mm |
| Weight | ~33 g (fan only) |
| Power supply | 13.2V DC (drawn from the radio's internal fan header) |
| Connector | 2-pin (plug-and-play with Washington internal header) |
| Control | Fully automatic via Washington APM (temperature-based) |
| Max fans supported by Washington | Up to 2 fans (two internal headers) |
How it works
The ACMD901 mounts directly to the four screw holes on the Washington's rear heatsink using the included screws and protective grille. The 2-pin connector plugs into a dedicated fan header on the Washington's main circuit board — no soldering, no cutting, no wire splicing. The wires tuck neatly into grooves molded into the case, so nothing sits loose or unprotected when the cover goes back on.
Once installed, the radio's APM (Automatic Power Management) circuit does the rest. APM continuously monitors internal temperature and switches the fan on automatically when the chassis heats up beyond a set threshold. If the radio still gets warmer than APM prefers, it will also gently reduce transmit power to keep everything within spec. You can also customize the fan-activation temperature threshold through the Washington's menu.
Single fan or two?
The Washington has two internal fan headers because it was designed with dual-fan cooling in mind. A single ACMD901 is a real, noticeable improvement over a bare heatsink and is enough for the majority of operators — trucker use, moderate SSB, and mixed-mode operation. If you run long high-power sessions on SSB DX, high-duty-cycle repeater nets, or a hot base station in the summer, the two-fan setup is the recommended maximum-cooling configuration. See our ACMD901 dual fan kit for the two-pack.
Installation
Installation is straightforward and takes most operators 20-30 minutes with basic hand tools. In outline:
- Disconnect the Washington from power.
- Remove the top case (screws are on the sides and rear). The original warranty stickers will break — this is expected. Two replacement stickers are included in the kit.
- Locate the two fan connectors on the main circuit board.
- Mount the fan to the rear heatsink using the four included screws and the protective grille.
- Route the fan wires into the case grooves and plug the 2-pin connector into an available header.
- Reinstall the case and apply the replacement warranty stickers over the original locations.
Full step-by-step instructions are included with the kit.
Frequently asked questions
Does the ACMD901 work with the older 80W Washington and the current 100W Washington?
Yes. President Electronics kept the same chassis, heatsink mounting pattern, and internal fan header layout across both Washington versions, so the ACMD901 is a universal fit.
Do I need one fan or two?
One fan makes a significant difference over the bare heatsink and is enough for most operators. Two fans give the Washington its maximum designed cooling capacity and are recommended for high-duty-cycle SSB, long repeater nets, and hot base station environments. The Washington has two internal headers specifically to support the dual-fan setup.
Will installing this fan void my President warranty?
No. The ACMD901 is a factory-approved accessory. President Electronics ships the kit with two replacement warranty stickers specifically so you can restore the warranty seals after installation. Use the included stickers to cover the original locations after buttoning the case back up.
Does the fan run all the time or only when needed?
Only when needed. The Washington's APM (Automatic Power Management) system controls the fan based on the radio's internal temperature. Under low-load conditions the fan stays off; under heavy transmit duty it engages automatically. You can also customize the activation threshold through the radio menu.
Is the ACMD901 loud?
No. The 40 mm fan is small and quiet, and because APM only spins it up when the chassis is genuinely warm, it stays silent for most of the operating time. It is noticeably quieter than an aftermarket muffin fan hard-wired to run continuously.
Can I install this myself, or do I need a tech?
Most operators can install the ACMD901 themselves in 20-30 minutes with basic hand tools. The connector is plug-and-play — no soldering, no wire splicing. Full instructions are included with the kit.
What's the mounting pattern and fan size, in case I want to source a replacement fan later?
The ACMD901 is a 40 × 40 × 20 mm 12V DC fan with a 2-pin connector. The mounting pattern matches standard 40 mm PC-style fan spacing (~32 mm hole-to-hole). That said, we strongly recommend sticking with the OEM ACMD901 — the connector, voltage, and grille geometry are all matched to the Washington, and third-party fans commonly have wrong wire polarity or connector pitch.
Ready to order
Add the ACMD901 to your cart along with your President Washington radio, or step up to the ACMD901 dual fan kit for the maximum-cooling two-fan configuration.
